Aruba Networks SFP-SX Compatible 1000BASE-SX SFP 850nm 550m MMF LC DOM Optical Transceiver Module


Aruba Networks SFP-SX compatible optical transceiver is a dual fiber 1000Mbps Small Form-factor Pluggable SFP module for use in 1000BASE Ethernet. SFP SX provides 1Gb/s throughput up to 550 meters over OM2 multi-mode fiber (MMF) using 850nm wavelength. This transceiver is fully compliant with SFP Multi-Source Agreement (MSA), IEEE 802.3z 1000BASE-SX and SERDES standard. Its electrical interface is MSA compliant 20-pin edge type connector and the optical interface is Duplex LC connector. The full-duplex SFP transceiver features highly reliable VCSEL transmitter and PIN photo detector to offer high performance interconnection at 1 Gbps data rate. Built-in Digital Diagnostic Monitoring (DDM) support is present for real-time performance monitoring via 2-wire Interface (TWI/I2C). Our modules are factory pre-programmed for compatibility, perform identically to original Aruba Networks SFP-SX transceivers.


Feature

  • Equivalent to Aruba Networks SFP-SX in function
  • Hot pluggable SFP form factor
  • Data rate up to 1000Mbps
  • 850nm VCSEL transmitter
  • PIN photo receiver
  • Duplex LC optical connector
  • Link distances up to OM2 550m
  • Built-in digital diagnostic via 2-wire interface
  • Single 3.3V power supply voltage
  • Power consumption < 0.6W
  • Ambient temperature range 0 to 70°C for commercial application
  • Compliant with INF-8074i, SFF-8472
  • Compliant with IEEE 802.3z 1000BASE-SX
  • Compliant with RoHS, REACH, CE, FCC standards

Application

  • Gigabit Ethernet

Specification

Aruba Networks Compatible P/N SFP-SX Form Factor SFP
Max Data Rate 1000Mbps Max Distance 550m (1804ft) @OM2
Wavelength 850nm Connector Duplex LC
DDM/DOM Support Media MMF
Transmitter Type VCSEL Receiver Type PIN
Transmitter Power -9.5 to -3dBm Receiver Sensitivity < -17dBm
Extinction Ratio 9dB Receiver Overload -3dBm
Modulation Format NRZ Power Budget 7.5dB
Power Consumption 0.6W Commercial Temperature Range 0 to 70°C (32 to 158°F)
