3m (9.84ft) Arista Networks CAB-Q56-Q56-3M Compatible 200G QSFP56 PAM4 Passive Direct Attach Twinax Copper Cable


Arista Networks CAB-Q56-Q56-3M compatible DAC is a passive 200Gbps QSFP56 to QSFP56 direct attach cable for use in 200GBASE Ethernet. QSFP56 DAC provides 200Gb/s throughput for 3m interconnection with high speed twin-axial copper cable. Standard length options cover from 0.5 meters to 3 meters. The QSFP56 DAC cable implements 4 independent 50 Gbps PAM4 transmit and receive signal channels in each differential pair for an aggregate 200 Gbps data rate. It also supports 4 channels 25 Gbps NRZ signals for 100 Gbps interconnection. This DAC is fully compliant with QSFP56 Multi-Source Agreement (MSA), IEEE 802.3cd 200GBASE-CR4 and 200GAUI-4 standard. The twin-axial copper cable's wire gauge is 28AWG and pre-terminated with MSA compliant 38-pin edge type connectors. MSA memory map are accessible via 2-wire Interface (TWI/I2C). Our DACs are factory pre-programmed for compatibility, perform identically to original Arista Networks CAB-Q56-Q56-3M direct attach cables.


Feature

  • Equivalent to Arista Networks CAB-Q56-Q56-3M in function
  • Hot Pluggable QSFP56 to QSFP56 Topology
  • Aggregate data rate up to 200Gbps
  • Pre-terminated 28AWG twin-axial copper cable
  • 4x 53.125Gbps PAM4 retimed 200GUAI-4 electrical interface
  • Minimum bending radius 35mm
  • MSA memory accessible via 2-wire interface
  • Single 3.3V power supply voltage
  • Extremely low power consumption near 0W
  • Ambient temperature range 0 to 70°C for commercial application
  • Compliant with SFF-8665, SFF-8661, SFF-8679, SFF-8636
  • Compliant with IEEE 802.3cd 200GBASE-CR4
  • Compliant with RoHS, REACH, CE, FCC standards

Application

  • 200G Ethernet
  • Data Center

Specification

Arista Networks Compatible P/N CAB-Q56-Q56-3M Topology QSFP56 to QSFP56
Max Data Rate 200Gbps Cable Length 3m (9.84ft)
Cable Type Twinax Wire Gauge 28AWG
Jacket Meterial OFNR (PVC) Minimum Bend Radius 35mm
Host FEC Support Modulation Format PAM4
Power Consumption 0W Commercial Temperature Range 0 to 70°C (32 to 158°F)
